Pepijn 187b2167ed feat(ci): benchmark smoke tests with isolated Docker images (LIBERO + MetaWorld) (#3319)
* docs(benchmarks): add benchmark integration guide and standardize benchmark docs

Add a comprehensive guide for adding new benchmarks to LeRobot, and
refactor the existing LIBERO and Meta-World docs to follow the new
standardized template.



* refactor(envs): move dispatch logic from factory into EnvConfig subclasses

Replace hardcoded if/elif chains in factory.py with create_envs() and
get_env_processors() methods on EnvConfig. New benchmarks now only need
to register a config subclass — no factory.py edits required.

Net -23 lines: factory.py shrinks from ~200 to ~70 lines of logic.



* docs(benchmarks): clean up adding-benchmarks guide for clarity

Rewrite for simpler language, better structure, and easier navigation.
Move quick-reference table to the top, fold eval explanation into
architecture section, condense the doc template to a bulleted outline.



* fix link

* fix task count

* fix: enable SmolVLA eval on LIBERO with custom camera mappings

- Thread camera_name_mapping from LiberoEnv config through to gym envs
- Sync features_map with camera_name_mapping in LiberoEnv.__post_init__
- Fix render() to use first available camera instead of hardcoded "image"
- Handle non-dict final_info in rollout by falling back to info["is_success"]
- Add use_peft legacy field to SmolVLAConfig for checkpoint compat
- Add defaults to GR00TN15Config init=False fields for transformers 5.3



* fix: use direct AutoresetMode import for gymnasium compat



* fix: handle gymnasium < 1.0 without AutoresetMode



* refactor: revert policy changes, keep env-only camera mapping fixes

- Revert GR00T N1.5 default_factory/default changes (transformers compat)
- Revert SmolVLA use_peft legacy field
- Apply ruff formatting fixes
- camera_name_mapping stays entirely in env/eval layer (no policy changes)



* Update docs/source/env_processor.mdx

Co-authored-by: Khalil Meftah <khalil.meftah@huggingface.co>
Signed-off-by: Pepijn <138571049+pkooij@users.noreply.github.com>

* feat(envs): lazy env init + AsyncVectorEnv as default for n_envs > 1

LiberoEnv and MetaworldEnv previously allocated GPU resources (EGL context,
OpenGL framebuffer) in __init__, before AsyncVectorEnv's fork(). Worker
processes inherited stale GPU handles, causing EGL_BAD_CONTEXT crashes on
first render.

Fix: defer OffScreenRenderEnv / MT1 construction to _ensure_env(), called on
first reset() or step() inside the worker subprocess. Each worker creates its
own clean context after fork().

Also fixes lerobot_eval.py:170 (add_envs_task TODO): replace with
env.call("task") which works with both SyncVectorEnv and AsyncVectorEnv.

AsyncVectorEnv is now the default for n_envs > 1; auto-downgraded to
SyncVectorEnv when n_envs=1 (no benefit, less overhead).

Expected speedup: ~15-20x for LIBERO Spatial with batch_size=50.



* fix: close envs between tasks to prevent worker process accumulation

eval_policy_all never closed environments after each task completed,
causing AsyncVectorEnv worker processes to accumulate (N_tasks × n_envs).
This led to OOM, BrokenPipeError and EOFError on multi-task benchmarks.

Also fixes:
- AsyncVectorEnv compat in envs/utils.py (use get_attr/call instead of .envs)
- Tuple task handling in tokenizer_processor and lerobot_eval
- _LazyAsyncVectorEnv for deferred worker spawning in LIBERO



* fix(eval): use task_description instead of task for language conditioning

env.call("task") returns the LIBERO task name with underscores
(e.g. "pick_up_the_black_bowl_...") instead of the natural language
description ("pick up the black bowl ..."). The VLM tokenizes these
completely differently, causing 0.0 reward across all episodes.



* docs: update adding_benchmarks for async env changes

- Replace add_envs_task reference with env.call("task_description")
- Update use_async_envs default to True
- Add note about lazy GPU init for AsyncVectorEnv compatibility



* feat(eval): batch_size=auto + faster env loading

- batch_size=0 (default) auto-tunes based on CPU cores, capped by
  n_episodes and 64. Removes the need for users to guess the right
  value. The old batch_size > n_episodes error is replaced by silently
  clamping to n_episodes.
- _LazyAsyncVectorEnv accepts pre-computed spaces so only one temp env
  is created per suite (not per task). For libero_spatial (10 tasks)
  this avoids 9 redundant LiberoEnv instantiations during env setup.



* docs: add evaluation guide and update benchmarks doc

- New docs/source/evaluation.mdx covering lerobot-eval usage, batch_size
  auto-tuning, AsyncVectorEnv performance, tuning tips, output format,
  multi-task evaluation, and programmatic usage.
- Add evaluation page to _toctree.yml under Benchmarks section.
- Update adding_benchmarks.mdx to reference batch_size auto default and
  link to the evaluation guide.



* docs(evaluation): remove benchmark table, rename section header



* perf(eval): shared memory, observation passthrough, task prefetch

- AsyncVectorEnv now uses shared_memory=True for zero-copy observation transfer
- LiberoEnvConfig.gym_kwargs passes observation_height/width to the env
- eval_policy_all prefetches next task's workers while current task runs



* style: ruff format



* chore: revert env_processor.mdx changes (not part of this PR)



* ci(benchmarks): add isolated integration tests for libero and metaworld

Each benchmark gets its own Docker image (lerobot[libero] / lerobot[metaworld]
only) so incompatible dep trees cannot collide. A 1-episode smoke eval runs
per benchmark on GPU runners.



* ci(benchmarks): pin action hashes and use uv sync --locked



* ci(benchmarks): trigger only on envs/ or lerobot_eval.py changes



* fix(ci): set LIBERO_DATA_FOLDER to bypass interactive stdin prompt

libero/__init__.py calls input() to ask about a custom dataset path,
which raises EOFError when stdin is closed inside Docker. Setting
LIBERO_DATA_FOLDER skips the prompt entirely.



* docs(benchmarks): add CI smoke test step to adding_benchmarks guide



* fix(ci): pre-create libero config in Dockerfile to bypass stdin prompt

libero/__init__.py calls input() when ~/.libero/config.yaml is missing.
We write the config at image build time (without importing libero) so
the prompt never fires at runtime. Also trigger CI on pyproject.toml changes.



* fix(ci): use shell to create libero config instead of multiline python -c

The multiline RUN python -c "..." was being parsed as Dockerfile
instructions. Use printf to write ~/.libero/config.yaml directly.



* fix(ci): point libero config to bundled package init_files

The config was pointing to /tmp/libero_init which doesn't exist.
Use importlib.util.find_spec to locate the hf-libero package directory
and write paths to the actual bundled bddl_files/init_files/assets.



* fix(ci): add smolvla extra to benchmark Dockerfiles

num2words (required by SmolVLM processor) is declared in lerobot[smolvla],
not lerobot[libero/metaworld]. Install both extras together.



* fix(eval): render_frame covers _LazyAsyncVectorEnv

isinstance(env, AsyncVectorEnv) silently skipped _LazyAsyncVectorEnv,
causing video rendering to produce no frames on the default async path.
Switch to hasattr(env, "call") so any async-compatible env (including
_LazyAsyncVectorEnv) hits the call("render") branch.



* refactor(envs): remove unused _get_sub_env_attr helper

_get_sub_env_attr was defined but never called anywhere in the codebase.
_sub_env_has_attr (its sibling) is kept — it is actively used in utils.py.



* chore: apply prettier formatting to docs



* docs(env_processor): remove deprecated add_envs_task from pipeline example

add_envs_task is replaced by env.call("task_description") in this PR.
Remove it from the pipeline walkthrough and renumber the steps (8→7).



* refactor(envs): remove __del__ from _LazyAsyncVectorEnv

__del__ is unreliable as a cleanup mechanism. close() is already called
explicitly in the eval loop's finally block, so the finalizer is redundant.



* fix(eval): prefetch next task's workers after close to avoid GPU memory overlap

Previously, next task's AsyncVectorEnv workers were spawned while the
current task was still running, causing both tasks' GPU contexts to coexist.
Moving the prefetch start into the finally block (after env.close()) ensures
workers for task N+1 only spin up once task N has released GPU memory.



* refactor(envs): move _LazyAsyncVectorEnv to utils and apply to metaworld

_LazyAsyncVectorEnv lived in libero.py but metaworld had the same OOM
problem: all tasks' AsyncVectorEnv workers were spawned eagerly, wasting
GPU memory for tasks not yet running.

Move the class to envs/utils.py so both environments share it, then apply
the same is_async + lazy wrapping pattern in create_metaworld_envs.



* chore: remove out-of-scope benchmark/CI/docs files from PR

Benchmark CI workflow, Dockerfiles, benchmark docs, evaluation smoke-test
doc, and dispatch tests belong in a separate PR. Scope this PR to the
async env init changes only.



* chore: restore adding_benchmarks + test_dispatch, drop env_processor changes

- Restore docs/source/adding_benchmarks.mdx (belongs in this PR)
- Restore tests/envs/test_dispatch.py (belongs in this PR)
- Revert docs/source/env_processor.mdx to main (out of scope for this PR)



* docs(adding_benchmarks): remove CI smoke test step (coming in separate PR)

Step 7 (Dockerfile + benchmark_tests.yml CI job) and its table rows are
out of scope for this PR. The CI infrastructure will be added on top in a
follow-up PR.



* refactor(envs): remove unused add_envs_task

Replaced by env.call("task_description") in lerobot_eval.py. No callers
remain in the codebase.



* style: fix prettier formatting in env_processor.mdx



* fix(ci): use root container chmod to fix PermissionError on artifact dirs

Running chmod on the host doesn't propagate into Docker due to UID/SELinux
mismatch. Instead, spin up the image as root to mkdir+chmod from inside
the container before the eval run mounts the same path.



* fix(ci): re-chmod artifacts after eval to fix unreadable files

Files created by user_lerobot inside the eval container inherit a
restrictive umask, making them unreadable by the runner after the
container exits. Add a post-eval 'docker run --user root' chmod step
so upload-artifact can find the video files.



* feat(ci): add monthly schedule trigger for benchmark tests

Runs on the 1st of every month at 02:00 UTC in addition to the
existing push/PR and manual dispatch triggers.



* fix(ci): change benchmark schedule from monthly to weekly (every Monday)



* fix(ci): use docker cp instead of bind mounts for artifacts

Bind mounts on these runners don't surface container-written files on
the host path (likely DinD/socket-mount setup). Switch to named
containers + docker cp, which copies directly through the daemon and
lands files in the runner's accessible filesystem.



* fix(ci): write eval output to /tmp inside container

user_lerobot cannot create /artifacts at the container root.
Use /tmp/eval-artifacts (always writable) then docker cp it out.



* feat(ci): add parse_eval_metrics step to benchmark workflow

Adds scripts/ci/parse_eval_metrics.py and wires it into both Libero and
MetaWorld jobs so the dashboard can read pc_success, avg_sum_reward and
eval_s from the metrics artifact instead of relying on GitHub step timing.



* feat(ci): add Libero train+eval smoke test (1 step, eval_freq=1)

Runs accelerate launch --num_processes=1 lerobot-train with:
- steps=1, batch_size=1, dataset.episodes=[0] (episode 0 only)
- eval_freq=1 so the training loop triggers eval after step 1
- eval.n_episodes=1, eval.use_async_envs=false

Tests the full train→eval-within-training pipeline in the existing
libero-benchmark-libero:ci image (no extra Docker build cost).
Uploads eval video from /tmp/train-smoke/eval/ as libero-train-smoke-video.



* feat(ci): extract task descriptions and embed in metrics artifact

- Add scripts/ci/extract_task_descriptions.py: runs inside the benchmark
  Docker container (LIBERO/MetaWorld installed) after lerobot-eval and
  writes task_descriptions.json mapping task keys to NL instructions.
  LIBERO: uses libero.libero.benchmark to get suite.get_task(i).language.
  MetaWorld: formats task name as human-readable label.
- Call extraction at the end of each eval bash-c (|| true so never fatal).
- parse_eval_metrics.py reads task_descriptions.json and includes it in
  metrics.json so the health dashboard Space can label videos by task.



* fix(ci): call extract_task_descriptions.py after eval in benchmark jobs

The task descriptions were never populated in metrics.json because
extract_task_descriptions.py was never invoked. The script exists and
parse_eval_metrics.py already looks for its output — the call was
simply missing from the workflow.

Appends the extraction step to the existing bash -c block (runs inside
the container where libero/metaworld is installed) so task_descriptions.json
is written to the eval-artifacts dir before docker cp copies it out.



* fix(test): use SyncVectorEnv in test_base_create_envs

AsyncVectorEnv spawns new subprocesses that do not inherit the
in-process gym registration created by the test. Pass
use_async_envs=False since this test validates dispatch logic,
not async parallelism.



* perf(ci): split Dockerfile dep-install from source-copy for faster rebuilds

The dep-install layer (uv sync) now only depends on pyproject.toml,
uv.lock, and a minimal package stub — not the full src/ tree. Source
code changes only rebuild the final COPY layer (seconds, not minutes).

Also switch from type=local cache (lost on ephemeral runners) to
type=gha (persisted in GitHub Actions cache, shared across all runs).

Before: every src/ change → full uv sync rebuild (~8-10 min)
After:  src/-only change → cached dep layer, ~30s source copy



* fix(ci): add Docker Hub login to avoid pull rate limits

Anonymous pulls from Docker Hub are rate-limited to 100/6h, which
fails when multiple benchmark jobs pull nvidia/cuda in parallel.
Add docker/login-action step (conditional on DOCKERHUB_USERNAME var)
to authenticate and get 200 pulls/6h.

Setup: add DOCKERHUB_USERNAME as a repository variable and
DOCKERHUB_TOKEN as a repository secret in GitHub Settings.



* fix(ci): use existing DOCKERHUB_LEROBOT_USERNAME/PASSWORD secrets



* fix(ci): use env context for secrets check in step if-condition

Step-level 'if' cannot reference 'secrets' directly. Expose the
secret via an env var and check that instead.



* fix(ci): simplify Docker Hub login to match existing workflows

Drop the conditional guard — other workflows (docker_publish,
full_tests) call docker/login-action unconditionally.



* fix(ci): switch Docker cache from type=gha to type=registry

GHA cache is capped at 10GB per repo — a single CUDA + PyTorch +
benchmark image is ~8GB so the cache evicts before it's reused.

Switch to type=registry which pushes cache layers to Docker Hub
(huggingface/lerobot-benchmark-cache:{libero,metaworld}). No size
limit, layers persist until explicitly deleted, and shared across
all runners and branches.



* fix(ci): use GHCR for Docker layer cache (Docker Hub push denied)

Docker Hub CI token can't push to new repos. GHCR works out of the
box — GITHUB_TOKEN has automatic packages:write for the repo owner.

- Add GHCR login step (github.actor + GITHUB_TOKEN)
- Switch cache refs to ghcr.io/huggingface/lerobot/cache-benchmark
- Add packages:write at job level (not workflow, per zizmor)
- Keep Docker Hub login for pulling nvidia/cuda base image



* fix(ci): remove GHCR cache (org blocks GITHUB_TOKEN package writes)

The huggingface org restricts GHCR package creation via GITHUB_TOKEN,
causing 403 on cache export. Remove all registry caching and GHCR
login. The Dockerfile layer split (deps vs source) still helps when
the runner has a warm Docker daemon.

Also fix the metaworld job which had a stale conditional Docker Hub
login and was missing the GHCR login entirely.



* fix(ci): address PR review feedback for benchmark smoke tests

Security:
- Remove "Login to Hugging Face" step — it was a no-op (ephemeral
  --rm container) that exposed the HF token via CLI argument in
  docker inspect / /proc/*/cmdline. The eval step already
  re-authenticates via env var.

Functional:
- Remove feat/benchmark-ci from push trigger branches (won't exist
  post-merge).

Dockerfiles:
- Pin uv to 0.8.0 (was unpinned, fetching whatever latest ships).
- Add comment explaining the chmod +x ptxas workaround (Triton
  packaging bug — ships ptxas without execute bit).

Scripts:
- parse_eval_metrics.py: add note that it runs on bare host and must
  stay stdlib-only.
- parse_eval_metrics.py: add NaN guard for avg_sum_reward and eval_s
  (was only guarding pc_success).



* ci(benchmarks): trigger on PRs targeting feat/benchmark-ci

Benchmark PRs (robomme, libero-plus, robocerebra, robotwin) target
feat/benchmark-ci, not main. Without this, the workflow never runs
on those PRs.



* fix(docker): use uv pip install instead of uv sync (cross-extra conflict)

uv sync --locked validates the entire lockfile across all extras.
Since robomme depends on mani-skill which pins numpy<2.0, and the
base project requires numpy>=2.0, the full lockfile is unsatisfiable.

Switch to uv pip install -e ".[libero,smolvla]" which only resolves
the requested extras for the current Python version and platform,
avoiding the cross-extra numpy conflict entirely.



* chore: revert configs.py, factory.py, test_dispatch.py to main

These use_async_envs default changes belong to the async-vector-env
PR (#3274), not this CI PR. Restore to match origin/main.



* fix: address PR review feedback — broken link, NaN guard, zizmor tags, fork skip

- Remove broken Triton issue link from Dockerfile.benchmark.libero
- Add module-level _safe_int helper to guard n_episodes against NaN
- Move _safe_float to module level alongside _safe_int
- Add # zizmor: ignore[unpinned-uses] to all upload-artifact@v4 steps
- Add if: env.HF_USER_TOKEN != '' to Libero smoke eval for fork PRs



* fix(ci): add fork PR guard to train-smoke and MetaWorld eval steps

Add if: env.HF_USER_TOKEN != '' to the Libero train+eval smoke and
MetaWorld smoke eval steps so fork PRs without the secret skip gracefully.



* fix(ci): remove feat/benchmark-ci from PR trigger branches



* refactor(docker): rebase benchmark images on nightly lerobot-gpu

Use huggingface/lerobot-gpu:latest as base for both libero and metaworld
benchmark Dockerfiles instead of building from nvidia/cuda scratch. The
nightly image already has all extras installed via uv sync --extra all,
so we only need to overlay the PR source code (and libero asset setup).

This eliminates duplicated system dep installation, Python setup, uv
venv creation, and the Triton ptxas workaround from both files.

---------

Signed-off-by: Pepijn <138571049+pkooij@users.noreply.github.com>
Co-authored-by: Khalil Meftah <khalil.meftah@huggingface.co>
2026-04-13 21:24:01 +02:00
2025-03-13 14:05:55 +01:00
2025-06-05 17:48:43 +02:00
2026-04-06 12:23:37 +02:00
2026-02-28 14:41:28 +01:00
2024-03-25 12:28:07 +01:00
2025-10-14 17:21:18 +02:00
2026-01-16 14:38:42 +01:00

LeRobot, Hugging Face Robotics Library

Tests Tests Python versions License Status Version Contributor Covenant Discord

LeRobot aims to provide models, datasets, and tools for real-world robotics in PyTorch. The goal is to lower the barrier to entry so that everyone can contribute to and benefit from shared datasets and pretrained models.

🤗 A hardware-agnostic, Python-native interface that standardizes control across diverse platforms, from low-cost arms (SO-100) to humanoids.

🤗 A standardized, scalable LeRobotDataset format (Parquet + MP4 or images) hosted on the Hugging Face Hub, enabling efficient storage, streaming and visualization of massive robotic datasets.

🤗 State-of-the-art policies that have been shown to transfer to the real-world ready for training and deployment.

🤗 Comprehensive support for the open-source ecosystem to democratize physical AI.

Quick Start

LeRobot can be installed directly from PyPI.

pip install lerobot
lerobot-info

Important

For detailed installation guide, please see the Installation Documentation.

Robots & Control

Reachy 2 Demo

LeRobot provides a unified Robot class interface that decouples control logic from hardware specifics. It supports a wide range of robots and teleoperation devices.

from lerobot.robots.myrobot import MyRobot

# Connect to a robot
robot = MyRobot(config=...)
robot.connect()

# Read observation and send action
obs = robot.get_observation()
action = model.select_action(obs)
robot.send_action(action)

Supported Hardware: SO100, LeKiwi, Koch, HopeJR, OMX, EarthRover, Reachy2, Gamepads, Keyboards, Phones, OpenARM, Unitree G1.

While these devices are natively integrated into the LeRobot codebase, the library is designed to be extensible. You can easily implement the Robot interface to utilize LeRobot's data collection, training, and visualization tools for your own custom robot.

For detailed hardware setup guides, see the Hardware Documentation.

LeRobot Dataset

To solve the data fragmentation problem in robotics, we utilize the LeRobotDataset format.

  • Structure: Synchronized MP4 videos (or images) for vision and Parquet files for state/action data.
  • HF Hub Integration: Explore thousands of robotics datasets on the Hugging Face Hub.
  • Tools: Seamlessly delete episodes, split by indices/fractions, add/remove features, and merge multiple datasets.
from lerobot.datasets.lerobot_dataset import LeRobotDataset

# Load a dataset from the Hub
dataset = LeRobotDataset("lerobot/aloha_mobile_cabinet")

# Access data (automatically handles video decoding)
episode_index=0
print(f"{dataset[episode_index]['action'].shape=}\n")

Learn more about it in the LeRobotDataset Documentation

SoTA Models

LeRobot implements state-of-the-art policies in pure PyTorch, covering Imitation Learning, Reinforcement Learning, and Vision-Language-Action (VLA) models, with more coming soon. It also provides you with the tools to instrument and inspect your training process.

Gr00t Architecture

Training a policy is as simple as running a script configuration:

lerobot-train \
  --policy=act \
  --dataset.repo_id=lerobot/aloha_mobile_cabinet
Category Models
Imitation Learning ACT, Diffusion, VQ-BeT, Multitask DiT Policy
Reinforcement Learning HIL-SERL, TDMPC & QC-FQL (coming soon)
VLAs Models Pi0Fast, Pi0.5, GR00T N1.5, SmolVLA, XVLA

Similarly to the hardware, you can easily implement your own policy & leverage LeRobot's data collection, training, and visualization tools, and share your model to the HF Hub

For detailed policy setup guides, see the Policy Documentation.

Inference & Evaluation

Evaluate your policies in simulation or on real hardware using the unified evaluation script. LeRobot supports standard benchmarks like LIBERO, MetaWorld and more to come.

# Evaluate a policy on the LIBERO benchmark
lerobot-eval \
  --policy.path=lerobot/pi0_libero_finetuned \
  --env.type=libero \
  --env.task=libero_object \
  --eval.n_episodes=10

Learn how to implement your own simulation environment or benchmark and distribute it from the HF Hub by following the EnvHub Documentation

Resources

Citation

If you use LeRobot in your project, please cite the GitHub repository to acknowledge the ongoing development and contributors:

@misc{cadene2024lerobot,
    author = {Cadene, Remi and Alibert, Simon and Soare, Alexander and Gallouedec, Quentin and Zouitine, Adil and Palma, Steven and Kooijmans, Pepijn and Aractingi, Michel and Shukor, Mustafa and Aubakirova, Dana and Russi, Martino and Capuano, Francesco and Pascal, Caroline and Choghari, Jade and Moss, Jess and Wolf, Thomas},
    title = {LeRobot: State-of-the-art Machine Learning for Real-World Robotics in Pytorch},
    howpublished = "\url{https://github.com/huggingface/lerobot}",
    year = {2024}
}

If you are referencing our research or the academic paper, please also cite our ICLR publication:

ICLR 2026 Paper
@inproceedings{cadenelerobot,
  title={LeRobot: An Open-Source Library for End-to-End Robot Learning},
  author={Cadene, Remi and Alibert, Simon and Capuano, Francesco and Aractingi, Michel and Zouitine, Adil and Kooijmans, Pepijn and Choghari, Jade and Russi, Martino and Pascal, Caroline and Palma, Steven and Shukor, Mustafa and Moss, Jess and Soare, Alexander and Aubakirova, Dana and Lhoest, Quentin and Gallou\'edec, Quentin and Wolf, Thomas},
  booktitle={The Fourteenth International Conference on Learning Representations},
  year={2026},
  url={https://arxiv.org/abs/2602.22818}
}

Contribute

We welcome contributions from everyone in the community! To get started, please read our CONTRIBUTING.md guide. Whether you're adding a new feature, improving documentation, or fixing a bug, your help and feedback are invaluable. We're incredibly excited about the future of open-source robotics and can't wait to work with you on what's next—thank you for your support!

SO101 Video

Built by the LeRobot team at Hugging Face with ❤️
S
Description
No description provided
Readme Multiple Licenses 783 MiB
Languages
Python 99.9%
